Capabilities

Not sure about a specific job(s)?

Head over to our Contact Page and let us know how we can help you!

Turning Centers

(Live Tool)



Doosan Puma 240GLMC W/FANUC Control (Gantry Load)

Max Turn = 12.50"

Max Length = 25.00"

With Live Tooling

Bar Capacity = 3.50

Stocking Unit

Live Tool - 7.5 HP, RPM=5000

DOOSAN 3100LY W/FANUC CONTROL W/HYDRAULIC STEADY REST

Max Turn = 16.53"

Max Length = 50.40"

5" Y-Axis

Hydraulic Steady-Rest

Live Tooling

4.00 Thru Hole

Live Tool – 7.5 HP, RPM 5000

DOOSAN PUMA 10HC Turning Center

Max Turn = 15.00"

Max Length = 20.00"

MORI SEKI SL25/1000 Turning Centers

Max Turn = 15.00"

Max Length = 39.00"

DOOSAN PUMA 240MC W/LNS BAR FEEDER W/FANUC CONTROL

Max Turn = 12.50"

Max Length = 21.00"

With Live Tooling

Bar Capacity = 3.50

Live Tool – 7.5 HP, RPM 5000

LNS Bar Feeder

DOOSAN PUMA 480 W/FANUC CONTROL

Max Turn = 35.00"

Max Length = 39.00"

Thru Hole = 6.50

HP = 60

MORI SEKI SL25/500 Turning Centers

Max Turn = 15.00"

Max Length = 20.00"

Horizontal Machining Center



Doosan NHP 8000

X = 55.1", Y = 47.2", Z = 53.9"

Max Workpiece Size 57" x 61" (H)

31.5" x 31.5" Twin Pallet Changer

Full 4th Axis Capability
90 Automatic Tool Changer
CAT50 Spindle Taper
50 HP, 10,000 RPM Spindle

Tool Breakage Detection

Renishaw Probing

In Process Renishaw Inspection



Vertical Machining Centers

DOOSAN MYNX 6500/50 (W/4th Axis)

Fanuc Control

X = 50″, Y = 26″, Z = 25″

30 Station Tool Changer

Coolant Through Spindle

6,000 RPM spindle

CAT50 Taper

Table 55″ x 26″

(2) FEMCO 3-AXIS VERTICAL MACHINING CENTER

Fanuc Control

Table 60” x 30”

40 Station Tool Changer

CAT50 Taper

Chevalier CNC Surface Grinder

Working Surface 20" x 40"

DOOSAN MYNX 5400/50 (W/4th Axis)

Fanuc Control

X = 40″, Y = 21”, Z = 21″

30 Station Tool Changer

Coolant Through Spindle

6,000 RPM Spindle

CAT50 Taper

Table 55’’ x 26’’


Horizontal Broaching

Keyways up to 1"

Splines up to 3-1/2"



Gear Hobbing

Max 1" D.P.

#240 Roller Chain 3" Pitch

Gear Cutting Up To 96" Diameter

Spline Lengths Up To 36" Long

Barber Coleman

Modul

Gleason Gear Generator

G&E

Pfauter

Fellows Gear Shaper



Fabrication

Miller PA1100HW - Robotic Welder

Mig Welding (GMAW) - Single Robot

Max Capacity: 1,100 lbs. per side

Fixture Centerline from Floor: 42"

Fixture Length: 60"

Shearing

Accurshear

10' x 1/4" Thick

MIG & TIG Welding

Large Weldments to Small Production Cells

Plate Roller

Lemas 3 roll

6' x 1/4" Thick

Accupress CNC Press Brake

250 Ton X 12'

Flame Hardening

Flame hardening up to 48" diameter

Automated Turntable Welding

Turntable welding up to 50" diameter

ALLTRA Plasma/Hypertherm HD Cutting Table

2″ Thick plasma capability

8' x 20' Sheet steel capabilities

True shape automatic nesting to reduce scrap

Hyperthem® plasma system for increased efficiency, accuracy & flexibility
